| Model |
SUN-3.6K-SG05LP1-EU-AM2-P |
SUN-5K-SG05LP1-EU-AM2-P |
SUN-6K-SG05LP1-EU-AM2-P |
SUN-7K-SG05LP1-EU-AM2-P |
SUN-7.6K-SG05LP1-EU-AM2-P |
SUN-8K-SG05LP1-EU-AM2-P |
SUN-10K-SG05LP1-EU-AM2-P |
| Battery Input Data |
| Battery Type |
Lead-acid or Lithium-ion |
| Battery Voltage Range (V) |
40–60 |
| Max. Charging Current (A) |
90 |
120 |
135 |
175 |
190 |
190 |
210 |
| Max. Discharging Current (A) |
90 |
120 |
135 |
175 |
190 |
190 |
210 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of battery input |
1 |
PV String Input Data Max. PV Access Power (W) 7200 10000 12000 14000 15200 16000 20000 Max PV Input Power (W) 5760 8000 9600 11200 12160 12800 16000 Max PV Input Voltage (V) 500 Start-up Voltage (V) 125 MPPT Voltage Range (V) 150–425 Rated PV Input Voltage (V) 370 Max Operating PV Input Current (A) 18+18 18+18 18+18 32+32 32+32 32+32 32+32 Max Input Short-Circuit Current (A) 27+27 27+27 27+27 48+48 48+48 48+48 48+48 No. MPP Trackers / Strings per MPPT 2 / 1+1 2 / 1+1 2 / 1+1 2 / 2+2 2 / 2+2 2 / 2+2 2 / 2+2
AC Input/Output Data Rated AC Input/Output Active Power (W) 3600 5000 6000 7000 7600 8000 10000 Max AC Apparent Power (VA) 3960 5500 6600 7700 8360 8800 11000 Rated AC Input/Output Current (A) 16.4/15.7 22.7/21.7 27.3/26.1 31.9/30.5 34.5/33.0 36.4/34.8 45.5/43.5 Max AC Input/Output Current (A) 18/17.2 25/23.9 30/28.7 35.0/33.5 38/36.3 40/38.3 50/47.9 Max Continuous AC Passthrough (A) 35 / 40 / 50 Peak Power (off-grid) 2× rated power (10s) Rated Input/Output Voltage Range (V) 220/230V (0.85Un–1.1Un) Grid Connection Form L + N + PE Grid Frequency Range 50Hz (45–55Hz) / 60Hz (55–65Hz) Power Factor Adjustment Range 0.8 leading – 0.8 lagging THDi <3% DC Injection Current <0.5% In
Efficiency Max Efficiency 97.60% Euro Efficiency 96.50% MPPT Efficiency >99%
Equipment Protection Integrated DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter (optional), Anti-islanding Protection, DC Switch,
Insulation Impedance Detection, Residual Current Detection Surge Protection Level TYPE II (DC), TYPE II (AC)
Interface Communication RS485 / RS232 / CAN Monitor Mode GPRS / WiFi / Bluetooth / 4G / LAN (optional)
General Data Operating Temperature Range -40 to +60°C (>45°C derating) Ambient Humidity 0–100% Altitude 2500m Noise <30 dB(A) IP Rating IP65 Inverter Topology Non-Isolated Over Voltage Category OVC II (DC), OVC III (AC) Cabinet Size (mm) 330 × 580 × 232 Weight (kg) 24.9 Warranty 5 Years / 10 Years The Warranty Period Depends the Final Installation Site of Inverter.
Refer to Warranty Policy for details. Grid Regulation IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G98, G99, VDE-AR-N 4105 Safety EMC Standards IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
